Home >> Products >> COJ0.35A Winch Lift Drum Dumper

Name：COJ0.35A Winch Lift Drum Dumper
Model：COJ0.35A
Product Introduction：A new range of Industrial drum lifter featuring easy raising and lowering properties, as well as portability, with various wheel and power options. They are kind to the operator and reduce fatigue.

Features:

1. The winch industrial drum lifter featuring easy raising and lowering , transporting and rotating properties, as well as portability, with various wheel and drum clamp options.

2. They are kind to the operator and reduce fatigue.

3. Applicable for chemical plants and food plants.

Model		COJ0.35A
Capacity	kg	350
Drum fixed type		hoop
Drum size		55 gallon steel (Ø572x900)
Max. lifting height	mm	1500
Load center	mm	415
Raised speed	mm/s	>35
Lowered speed		Controllable
Leg width	mm	680
Max. ground clearance	mm	30
Wheel	mm	Ø200x50/Ø100x45
Overall dimension	mm	1250x750x1900
Service weight	Kg	145
