Name:DTF300 DTF300B (DR300B) semi-electirc drum dumper (new)
Model:DTF300 DTF300B (DR300B)
Product Introduction:1. Power drive, lift, rotate and tilt for ergonomic drum pouring. 2. Heavy duty design with the load capacity to 300kg.

Semi-Electric Drum Tilter DTF300B

1.     Power drive, lift, rotate and tilt for ergonomic drum pouring.

2.     Heavy duty design with the load capacity to 300kg.

3.     It allow you to move drums on and off shipping pallets, spill containment pallets and drum dollies.

4.     The V-shaped base is designed so you can raise and place a drum at the corners of a pallet;

5.     The drum can electric rotate 180 degree;

Model DTF300B
Rated Load Capacity kg 300
Drum Size 55gallon(Ф572×900)or 80gallon(Ф800×900) 210L Plastic
plastic or steel drum
Lifting Height mm 1100
Lifting Speed mm/s 80
Pouring Height mm 1300
Caster Wheelfront/back mm Ø150x50 / Ø125x50
Turning Radius mm 1500
Pump Station Power KW/h 0.8
Battery V/Ah 12/100
Overall Size mm 1500x1350x1870
Net Weight kg 230
