Home >> Products >> YL350 Electric Drum Racker

Name：YL350 Electric Drum Racker
Model：YL350
Product Introduction：1. Special design for handling all size of drums. 2. All electric control, ideal for lifting, rotating and stacking drum or other round goods such as paper roll and move drums on and off racks, pallets, trucks, etc; 3. Equipped with VARTA maintenance-free battery 4. Lift an upright drum and place in horizontal position;

1. Special design for handling all size of drums.

2. All electric control, ideal for lifting, rotating and stacking drum or other round goods such as paper roll and move drums on and off racks, pallets, trucks, etc;

3. Equipped with VARTA maintenance-free battery

4. Lift an upright drum and place in horizontal position;

Model		Power-Propelled Drum Racker YL350
Rated load capacity	kg	350
Wheel size	mm	80*55 (Front)	150*50 (Rear)
Inside/Outside width of Support leg	mm	640 (inside)	800 (outside)
Turning radius	mm	1500
Pump station power	Kw/h	1.5
Batter	Ah/V	120Ah/12V
Lifting height	mm	1250(upright drum)	2000(horizontal drum)
Lifting speed	mm/s	120
Acceptable drum type	mm	55 gallon drum
Overall size	mm	12508402200
Net weight	kg	410
