Power
High quality assembly from the relative or the near industries makes strong power system and high steadiness in quality.
1.Strong power, easy work
Capacity 1.5ton, solving all problems in good transit
Comparing to hand pallet truck, more efficient and convenient while lifting, lowering and walking
2.High quality assembly makes the truck durable solid body frame
Delicacy
Reasonably removing unnecessary accessories to save materials and improve body frame intensity.
1.Pretty appearance
Semi-enclosed appearance design, brief and elegant
2.Delicacy structure with excellent detail
Delicacy inner and outer structure design with excellent details.
3.Easy to maintenance
Modular produce, easy to dismantle and assemble 85AH battery, free maintenance.
Mini
Ingenious designed, increase the space utilization.
1.Small body to save space
Small size makes passing in narrow pathway easily
2.Agility and convenience in operation
Light body makes operation conveniently
3.Economic and energy saving
High quality with good price, origin design revolutionary truck forklift industry
85AH battery, energy saving and environment protective
|
Model
|
EPT20-15ET2
|
|
Rated load(kg)
|
1500
|
|
Load center B11(mm)
|
600
|
|
Operation type
|
Walking style
|
|
Standard fork width b5(mm)
|
560(685)
|
|
Fork length(mm)
|
1150
|
|
Fork thickness(mm)
|
50
|
|
Fork width(mm)
|
150
|
|
Overall length(mm)
|
1638
|
|
Minimum turning radius(mm)
|
1485
|
|
Minimum channel width(1000x1200mm,Tray)(mm)
|
1739
|
|
Minimum channel width(800x1200mm,Tray)(mm)
|
1939
|
|
Maximum running speed, full load / no load(km/h)
|
4/4.5
|
|
Maximum lifting speed, full load / no load(m/s)
|
0.029/0.038
|
|
Maximum down speed, full load / no load(m/s)
|
0.046/0.033
|
|
Dead weight with battery(kg)
|
195
|
|
Tire material
|
Polyurethane
|
|
Running power(kw)
|
0.65
|
|
Lifting power(kw)
|
0.84
|
|
Voltage / capacity(V/Ah)
|
24/65
|
|
Running braking
|
Electromagnetic brake
|
|
Brake
|
Battery brake
|
