Name:CBE2.0 Full Electric pallet truck
Model:CBE2.0
Product Introduction:1.Hydraulic pump station makes the lifting of goods steady and powerful 2.Drive wheel installed with reliable dish style braking has strong power and steady capability 3.Electric control system reacts quickly and operates easily 4.It has flexible linear heavy-duty design and tight structure, and it is suitable for narrow access and is flexible operated 5.It is accorded to European standard of EN1757-1: 2001

CBE2.0 ELECTRIC PALLET TRUCK

·Strong chassis bears long-term and heavy duty.

·Horizontal driving wheel unit. Wheel replaces simply.

·CURTIS controller, MAHLE hydraulic motor.

·Stepless speed control, slow travel switch optional.

·Standing pedal, handrails, and electromagnetic brake.

·Safety features include a horn, belly reverse button and an emergency switch.

·Driving  motor  AC  and DC optional.

Model No.

CBE2.0- AC

Platform (15kg)

without/with

Capacity

(kg)

2000

Load Center

C (mm)

600

Max. Fork Height

H (mm)

205

Min. Fork Height

h (mm)

85

Fork Length

L1 (mm)

1150

Individual Fork Width

b (mm)

160

Wheel Base

y (mm)

1406

Turning Radius

Wa (mm)

1608/1946

Working aisle with 800x1200 pallet

(mm)

2646

Traveling Speed With/Without Load

(Km/h)

3.6/5.4

Lifting Speed With/Without Load

(mm/s)

22/32

Lowering Speed With/Without Load

(mm/s)

50/55

Drive Wheel

1200W, Ф250x80mm (AC)

Power Unit (lifting motor)

(W/V)

800/24

Traction Battery

24V/210Ah, 185kg

Battery Charger

25A/24V

Overall Dimension (L×W×H)

(mm)

1781×690×1305 /2125x690x1305

Fork Overall Width

B (mm)

530/680

Net Weight

(kg)

324/329
