Home >> Products >> CTDS Roughly Type Semi-Electric Stacker

Name：CTDS Roughly Type Semi-Electric Stacker
Model：CTDS
Product Introduction：This Stackers combine power and simplicity into these walk behind type units. The Stackers are ideal for small workspaces and production areas. They can lift up to 1,000kg (2,200 lb) loads with ease. The forks operate smoothly up and down by hydraulic system powered by a 12V DC Motor.

Features:

1. Max. load weight: 1,000kg (2,200lbs).

2. 12V DC hydraulic system.
3. Operates smoothly up and down .
4. Compact design and top quality mast construction.
5. Safety guard on load roller and steering wheel.
6. Light and easy manual steering system.
7. Combines power and simplicity.
8. Ideal for small workspaces and production areas.

Model No.		CTDS1000-16
Rated Capacity	kg	1000
Lifting Height	mm	1600
Fork Length		1000
Fork Width		310-660
Load Center		400
Minimum Turning Radius		1350
Lifting Motor	V/Kw	12/1.5
Battery	V/Kh	12/100
Charger	V/Kh	12V 50Hz
Overall Length(A)	mm	1500
Overall Width(B)		850
Overall Height(H1)		2000
Net Weight	kg	272
*Fix forks available
