▼Standard Safety Features:
● Upper platform fitted with aluminum safety bar preventing descent on contact with obstructions;
●Low-tention (24V) control box with up-down buttons;
●Internal power pack equipped with relief valve against overloading and compensated flow valve for controlled lowering speed;
● Heavy duty cylinders with drainage system and check valve to stop the lift table lowering in case of horse burst;
● Safety clearance between scissors to prevent trapping during operation.
▼Other Standard Features:
●Self lubricating bushings on pivot points;
●Removable lifting eye to facilitate handling and lift table installation.
MODEL
|
Capacity
|
Lowered/Raised/Height
|
Platform Size
|
Base Size
|
Lift Time
|
Power Pack
|
N.W
|
HW1001
|
1000
|
205/990
|
820*1300
|
640*1240
|
20-25
|
380V/50HZ 1.1Kw
|
160
|
HW1002
|
1000
|
205/990
|
1000*1600
|
640*1240
|
20-25
|
380V/50HZ 1.1Kw
|
186
|
HW1003
|
1000
|
240/1300
|
850*1700
|
640*1580
|
30-35
|
380V/50HZ 1.1Kw
|
200
|
HW1004
|
1000
|
240/1300
|
1000*1700
|
640*1580
|
30-35
|
380V/50HZ 1.1Kw
|
210
|
HW1005
|
1000
|
240/1300
|
850*2000
|
640*1580
|
30-35
|
380V/50HZ 1.1Kw
|
212
|
HW1006
|
1000
|
240/1300
|
1000*2000
|
640*1580
|
30-35
|
380V/50HZ 1.1Kw
|
223
|
HW2001
|
2000
|
230/1000
|
850*1300
|
785*1220
|
20-25
|
380V/50HZ AC 2.2Kw
|
235
|
HW2002
|
2000
|
230/1000
|
1000*1600
|
785*1220
|
20-25
|
380V/50HZ AC 2.2Kw
|
268
|
HW2003
|
2000
|
250/1300
|
850*1700
|
785*1600
|
25-35
|
380V/50HZ AC 2.2Kw
|
289
|
HW2004
|
2000
|
250/1300
|
1000*1700
|
785*1600
|
25-35
|
380V/50HZ AC 2.2Kw
|
300
|
HW2005
|
2000
|
250/1300
|
850*2000
|
785*1600
|
20-35
|
380V/50HZ AC 2.2Kw
|
300
|
HW2006
|
2000
|
250/1300
|
1000*2000
|
785*1600
|
25-35
|
380V/50HZ AC 2.2Kw
|
315
|
HW4001
|
4000
|
240/1050
|
1200*1700
|
900*1600
|
30-40
|
380V/50HZ AC 2.2Kw
|
375
|
HW4002
|
4000
|
240/1050
|
1200*2000
|
900*1600
|
30-40
|
380V/50HZ AC 2.2Kw
|
405
|
HW4003
|
4000
|
300/1400
|
1000*2000
|
900*2000
|
45-50
|
380V/50HZ AC 2.2Kw
|
470
|
HW4004
|
4000
|
300/1400
|
1200*2000
|
900*2000
|
45-50
|
380V/50HZ AC 2.2Kw
|
490
|
HW4005
|
4000
|
300/1400
|
1000*2000
|
900*2000
|
45-50
|
380V/50HZ AC 2.2Kw
|
480
|
HW4006
|
4000
|
300/1400
|
1200*2200
|
900*2000
|
45-50
|
380V/50HZ AC 2.2Kw
|
505
|
HW4007
|
4000
|
350/1300
|
1700*1500
|
1620*1400
|
35-45
|
380V/50HZ AC 2.2Kw
|
570
|
HW4008
|
4000
|
350/1300
|
2200*1800
|
1620*1400
|
35-45
|
380V/50HZ AC 2.2Kw
|
655
|
