Home >> Products >> SL&PL Manual Scissor Skid Lifter

Name：SL&PL Manual Scissor Skid Lifter
Model：SL&PL
Product Introduction：Skid Lifter SL/PL series Correctly position skids and work surfaces to minimize back strain 1.Combination of pallet truck and lift table. 2. Ideal for your loading and unloading operations. 3. Continuous-welded heavy steel frame and forks handle weighty loads with ease. 4. Easy-to-use control lever, plus two parking brakes on steering wheels increase safety. 5. A foot-operated pedal for easier and faster lifting. 6. Additional steering handle on 1000kg models for easier and more comfortable turning. 7. Conforms to EN 1757-4.

Skid Lifter SL/PL series

Correctly position skids and work surfaces to minimize back strain

1.Combination of pallet truck and lift table.
2. Ideal for your loading and unloading operations.
3. Continuous-welded heavy steel frame and forks handle weighty loads with ease.
4. Easy-to-use control lever, plus two parking brakes on steering wheels increase safety.
5. A foot-operated pedal for easier and faster lifting.
6. Additional steering handle on 1000kg models for easier and more comfortable turning.
7. Conforms to EN 1757-4.

Model		SL50S	SL50L	SL100S	SL100L	PL50S	PL50L	PL100S	PL100L
Type		without platform				with platform
Capacity	(kg)	500		1000		500		1000
Max.Fork Height	H(mm)	830				833
Min.Fork Height	h(mm)	85				88
Fork/Platform Length	L(mm)	1115				1115
Fork/Platform Width	W(mm)	526	690	526	690	538	703	538	703
Pump Strokes to Max.Lift		45		75		45		75
Front Roller	(mm)	Ø70x68 polyurethane				Ø70x68 polyurethane
Steering Wheel	(mm)	Ø150x40 polyurethane				Ø150x40 polyurethane
Overall Length	L1(mm)	1550		1640		1550		1640
Overall Width	W1(mm)	526	691	687	852	538	703	693	858
Overall Height	H1(mm)	1012		1307		1012		1307
Net Weight	(kg)	107	116	135	138	122	136	150	158
