Name：FSJY6 Self Propelled Scissors Aerial
Model：FSJY6
Product Introduction：lifting table has functions of self-walking and turning drive，can walk fastly and slowly in different working state and only one person needed can load and unload aerially. It is specially suitable for larger working areas such as airport termainal,station,dock,market, stadium, property of areas,factory and workshop,etc.

lifting table has functions of self-walking and turning drive，can walk fastly and slowly in different working state and only one person needed can load and unload aerially. It is specially suitable for larger working areas such as airport termainal,station,dock,market, stadium, property of areas,factory and workshop,etc.

Model Number		FSJY6
Max.Platform Height	mm	6000
Max.Machine Height	mm	7100
Min.Platform Height	mm	1010
Ground Clearance	mm	90
Lift Rated Capacity	kg	300
Platform Extend Capacity	kg	100
Platform Size	mm	1870×730
Platform Extend Length	mm	900
Max.Drive Speed (platform Stowed)	km/h	3~4
Max.Drive Speed (platform Elevated)	km/h	0.6~1
Min.turning Radius	mm	1900
Max.Climbing Capacity	%	10~15
Driving Wheel Size	mm	φ250×80
Caster Size	in	8
Driving Motor	v/kw	2×24/0.5
Lifting Motor	v/kw	24/2.2
Anerold battery	v/Ah	2×12/150
Charger	V/A	24/20
Overall Length	mm	2030
Overall Width	mm	900
Overall Height	mm	2120
Overall Net Weight	kg	1300
