Name:DTW250 Drum Truck
Model:DTW250
Product Introduction:Ideal for lifting and transporting steel drums with a top lip. Straddle leg for picking up drum from a Euro Pallet. Spring-loaded steel jaws securely grip the top lip of the drum.

Features:

1. Ideal for lifting and transporting steel drums with a top lip.

2. Straddle leg for picking up drum from a Euro Pallet.

3. Spring-loaded steel jaws securely grip the top lip of the drum.

4. Simple design is easy to use;unit features a manual mechanical hand ratchet crank lift mechanism.

5. Includes two rigid and one locking swivel caster.

Model DTW250
Lifting capacity kg 250
Lifting height mm 200250/300
Lifting per stroke mm 22
Wheel size mm Ф180/Ф125
Drum Size 572mm(22.5"Diameter),210Lifters (55gallon)
Overall dimensions mm 830*1010*1060
Net weight kg 45
