Name：FE800A Electric Hydraulic Drum Rotator
Model：FE800A
Product Introduction：Electric Hydraulic Drum Rotator FE800A Move & Pour Drums Lift, move and pour up to 72" /1830mm high Rotate drum 360 degrees in either direction. AC, DC or Air lift and tilt Power Options. Capacity: 365kg/800 lbs. One Person can safely and easily lift, move and control the puring of a 55-gallon steel drum weighing up to 800 lbs. with minimal physical effort. Simply control the dump tilt angle and the contents are discharged straight forward directly from the drum. There are many options with manual, worm gear, chain wheel and electric 360 degree flipping to handle a variety of plastic, steel and fiber drums. Anti-falling electric design provides safe and labor-saving operation.

Electric Hydraulic Drum Rotator FE800 FE800A

Move & Pour Drums Lift, move and pour up to 72" /1830mm high

·Rotate drum 360 degrees in either direction.

·AC, DC or Air lift and tilt Power Options.

·Capacity: 365kg/800 lbs.

lOne Person can safely and easily lift, move and control the puring of a 55-gallon steel drum weighing up to 800 lbs. with minimal physical effort.

lSimply control the dump tilt angle and the contents are discharged straight forward directly from the drum.

lThere are many options with manual, worm gear, chain wheel and electric 360 degree flipping to handle a variety of plastic, steel and fiber drums.

lAnti-falling electric design provides safe and labor-saving operation.

Model		FE800A	FE800A
Capacity	kg/lbs	365(800)	365(800)
Drum size		30 gallon (Ø450x700)-55 gallon ( (Ø572x900) steel, 210L plastic
Rotating type		Mechanical Chain wheel	Gear Motor
Lifting height	mm	812-1830 (32-72 inch)	812-1830 (32-72 inch)
Steering Wheel	mm	Φ200	Φ200
Load Wheel	mm	Φ125	Φ125
Lifting Motor	V/W	12/800	12/800
Battery	V/Ah	12/60	12/60
Drum tilting degree	degree	90°~180°~360°
Outline dimension	mm	1180x1150x1260	1180x1150x1260
Net weight	kg	248	251
