Name:3.5 Ton Gas LPG Forklift (CPYD35G)
Model:CPYD35G
Product Introduction:Built to last, this ergonomically designed forklift has a spacious operator's compartment and access from both sides. The LPG version is a dual fuel forklift and comes with a swing down LPG bottle bracket to allow safe and efficient bottle changes.

The G series is built to international standards to boost your productivity. The Drive train is powered by an indigenous, powerful engine that is environment friendly. And an indigenous power shift automatic torque converter transmission with soft touch electric gear shift and inching control for precise load and truck movements. With travel speeds of up to 20km/h and lift/lower speeds of 0.5m/set; with grade ability of up to 28%, few forklifts can match the G series in performance. You also have lifting height options up to 6 meters and a range of fitments and attachments such as clamps for paper reels, drums, bales, etc.

With its unsurpassed travel speed, you can service more stations faster. The lifting and lowering speeds are faster. The small turning radios ensure that you move between aisles fasters. Your operations can work smarter as there is better visibility and comfort at all times. And with cycle times reduced you will see how the G series can do wonders to your productivity.

An internal combustion counterbalanced forklift, this forklift truck has a swing down LPG bottle bracket to allow safe and efficient bottle changes. Ergonomically designed with a spacious operator's compartment and access from both sides.

Awarded with the innovation by the economic affairs for its exquisite design and super performance.

Providing different accessory to satisfy the customer's need.

The attachments come out differently due to the different need for the different operation places.

Special equipment like vertically standing exhaust pipe, warning light, rear light, wet-type air filter and fork attachment, etc.

Model

CPYD35G-H2

1

Power Type

Gasoline/LPG

2

Rated Capacity

kg

3500

3

Load Centre

mm

500

4

Lift Height

mm

3000

5

Fork Size (L×W×T )

mm

1070×125×50

6

Mast Tilt Angle (F/R)

Deg

6°/12°

7

Front Overhang (Wheel center to fork face)

mm

490

8

Ground Clearance(Bottom of mast)

mm

120

9

Turning Radius (outside)

mm

2445

10

Min. Intersecting aisle

mm

2235

11

Max.Gradeability (No load/Full load)

%

20

12

Wheelbase

mm

1700

13

Service weight

kg

4675

14

Battery (Voltage/Capacity)

V/Ah

12/90

15

Overall Dimension

Length to face of fork(Without fork)

mm

2700

16

Overall Width

mm

1225

17

Mast Lowered Height

mm

2125

18

Mast Extended Height(With backrest)

mm

4150

19

Overhead Guard Height

mm

2090

20

Speed

Travel (No load)

km/h

19

21

Lifting(Full load)

mm/s

410

22

Tire

Front

mm

28×9-15*

23

Rear

mm

6.50-10-10PR

24

Engine

Model

K25

25

Manufacture

NISSAN

26

Rated output/r.p.m.

kw

37.4/2300

27

Rated torque/r.p.m.

N·m

176.5/1600

28

No.of Cylinder

4

29

Bore×Stroke

mm

89×100

30

Displacement

cc

2488

31

Fuel Tank Capacity

L

70

32

Transmission

Type

Powershift (Manual)

33

Stage FWD/RVS

1/1(2/2)

34

Operating Pressure for Attachment

Mpa

17.5
