Name：1.0 Ton Three Wheel Electric Forklift (CPD1.0F)
Model：CPD1.0F
Product Introduction：The new Enforcer 3-Wheel Battery Electric Forklift was ergonomically designed for easy maneuverability and superb load handling in tight spaces.

Electric Forklift 3 Wheel Features

1. New design reinforced roof frame with superior anti roll ability.

2. Professional electronic control proportional technology system, it has better performance than diesel forklift.

3. AC motor driving and lifting electric control system greatly reduce the difficulty of forklift maintenance.

4. It is equipped with the sixth generation cylinder buffer technology as standard to ensure high efficiency, energy saving and more reliable stability.

5. The whole vehicle equipped with two degrees of freedom steering front and back, left and right, more comfortable operation experience.

6. It has 24 degree cone seal greatly as standard to reduce the possibility of hydraulic system leakage.

7. The three-stage deceleration integral axle can reduce the driving noise and enhances the kinetic energy conversion ratio.

8. Large capacity acid battery is fully charged within 2 hours, greatly improving the economy.

9. More than 2000hours of rechargeable acid batteries (optional) ensure the forklift's continuous operation ability and service life time.

10. The high performance charger can achieve 93% charging efficiency and reduce the cost continuously.

CPD-F series 3-fulcrum mini electric forklift (3-wheeled )
Model	CPD1.0F
Capacity Q	1000
Load Center ©	400（500）
Lifting Height h3	3200
Free Lifting Height h2	1600
Fork Length	800（1000）
Fork Sideswith	100
Type of Lifting	Electric Hydralic
Speed of Lifting	>200
Speed of Lowering	adjustable
Title of mast α/β	2° /5°
Height of Mast Lowered h1	2080
Height of Mast Extended h4	3680
Height of Overhead Guard	1900
Height of Seat from Ground	850
Length of the face of fork	1350
Overallwidth	800
Thread (Front wheel)	950
Thread (Rear wheel)	1030
Wheelbase	660
Ground Clearance	90
Turing Radius	1240
Steering System	Hydraulic
Type of Drive	Electric Motor
Drive speed(load/unload)	6.0/7.0
Speed Control	MOFSET
Gradeability	8
Driving brake	Hydraulic Brake System
Parking brake	Hand Brake
Battery	D-385
Weight of battery	390
Weight of truck	1550
Driving Motor	3
lifting motor	5
Wheel (front/rear)	Solid Rubber
Dimension of Front Wheel	φ267x127x165.1
Dimension of Drive Wheel	φ267x127x165.1
