Name：WS-150/16RT-AC WS-130/20-AC WS-130/25-AC WS-130/30-AC Rough Terrain Electric Pallet Stacker
Model：WS-150/16RT-AC
Product Introduction：This pallet stacker has straddle legs which provide great stability. The large wheels and raised chassis make it ideal for rough terrain. It is suitable for loading, unloading and transportation of most standard pallets.

Name:Rough Terrain Stacker

This Rough Terrain Stacker has straddle legs which provide great stability. The large wheels and raised chassis make it ideal for rough terrain. It is suitable for loading, unloading and transportation of most standard pallets.

Rough Terrain Stacker is Designed with 2 independently powered drive wheels.

This rough terrain stacker can travel inclines of up to 1500kg. The rough terrain pallet stacker can for example be used in underground car parks and travel up ramps between levels.

The Electric Rough Terrain Pallet Stacker is also available with raised fork heights of 3000mm. Please contact us for more information.

Parameter	WS-150/16RT-AC	WS-150/20RT-AC	WS-150/25RT-AC	WS-150/30RT-AC	Unit	Notes
Model	WS-150/16RT-AC	WS-150/20RT-AC	WS-150/25RT-AC	WS-150/30RT-AC	-
Driving Motor	1500W	/	/	/	W	Common for all models
Lifting Motor	2000W	/	/	/	W	Common for all models
Controller	CURTIS 1232E-2121 (180A)	/	/	/	-	Common for all models
Drive Wheel	300 × 125mm	/	/	/	mm	Solid rubber tire
Load Wheel	406 × 110mm	/	/	/	mm	Solid rubber tire
Inner Width of Straddle Leg	1270 / 1070	/	/	/	mm	Dual options
Mast	121	/	/	/	-	Mast type
Load Capacity	1500	/	/	/	kg	Common for all models
Fork Length	1070	/	/	/	mm
Fork Width	≤840	/	/	/	mm	Max width
Lifting Height	1600	2000	2500	3000	mm	Key differentiating feature
Battery	2 × 12V/120Ah	/	/	/	-	Common for all models
Charger	24V/15A	/	/	/	-	Common for all models
